High transparency and see-through design - maintains clear visibility while displaying vibrant content
Lightweight and wind-resistant - modular grid structure ensures durability and airflow for outdoor applications
Energy-efficient bright LEDs - delivers sharp visuals with low power consumption
Customizable and flexible - supports various shapes and sizes for creative installations

Get a quote

Seekway Innovations Technology Co., Ltd.

READY TO GET A SAMPLE?

Contact

Download

Specifications · CT135B系列 · 七列等宽 + 合并居中

LED Specifications
Model	CM30-P50D	CM30-P55D	CM30-P63D	CM30-P72D	CM30-P83D	CM30-P100D
Pixel Pitch	50mm	55mm	62.5mm	71.5mm	83mm	100mm
Pixel	400Pixel/M²	324Pixel/M²	256Pixel/M²	196Pixel/M²	144Pixel/M²	100Pixel/M²
Dot Size	30×30×16mm
LED Type	3535SMD RGB
Pixel Composing	3 LEDs/Pixel
LED Color	RGB, RGBW, RGB+W
Control Mode	DMX512
Input Voltage	DC 12V
Power Consumption	0.6W/Pixel
Grey Scale	16bit
Beam Angle	≥120°
Surface Color	Transparent and black available
Refresh Rate	16K
Shell Material	High and low temperature resistant flame retardant PVC
PCB material	FR-4
Ingress Protection	IP67
Operating Temp	-30℃—70℃
Service Life	>80000h

Luminosity Distribution

Installation Method

The control system is integrated with the power supply, utilizing a hook-and-lift design or aluminum clip-based force distribution with left and right latches for fixation. It features user-friendly operation, eliminating the need for complex wiring. Maintenance can be conducted from both the front and rear, and single-point maintenance allows for the easy and quick removal of faulty points and replacement with new ones.
